LaserCube Academy · Intermediate

Control modes for the Ultra MK2 and Pro

Eight short lessons on running your cube without a laptop, or from your lighting desk: your own playlists from the SD card, shows that follow the music, laser shows on several cubes at once, DMX and Art‑Net, and MIDI controllers. Pass the final quiz and download your certificate.

  • 8 lessons + quiz, about 45 minutes plus videos
  • Ultra MK2 & Pro
  • No account needed
  • Free certificate
Course contents0 of 8 lessons done

The questions, the final quiz and the certificate need JavaScript. Without it you can still read every lesson below.

Before you start

How this course works

Streaming from LaserOS is only one way to run your cube. This course shows you the others: the cube playing on its own from its SD card, a lighting desk in charge, and knobs and buttons on a MIDI controller.

By the end you can

  • pick the right control mode for a job, and know which settings the cube uses in it;
  • put your own playlist on the SD card and play it from the cube’s screen or a web browser;
  • make the Visualizer follow the music, from the built‑in microphone or the line input;
  • play a built‑in laser show on several cubes in sync with Cube Link;
  • connect a DMX or Art‑Net desk and read the cube’s 16 channels;
  • use and map an APC40 MK2 or APC mini MK2 MIDI controller.

How the lessons work

  • Each lesson takes about 5 minutes, plus any video. It has the key points and a few questions, and most have a video or pictures. Get a question wrong? Pick another answer.
  • Your progress is saved in this browser. There’s no account and nothing is sent to us. Clearing your browser data, or switching to another device, starts the course again.
  • When all eight lessons are done, take the final quiz: 10 questions, 8 right to pass, as many tries as you need.
  • Pass, then download your certificate as a PDF or an image.
Do “Laser safety” first

Every rule from the Laser safety course applies in every control mode: the beam block set before the show, every beam at least 3 m (10 ft) above people, a main and a backup way to stop it, and only people trained in laser safety at the controls. Where people could get into the beams, every beam and where it lands stays in view of someone who can stop the laser; with every beam at least 3 m (10 ft) above the highest place anyone can stand, it may run with nobody watching, on the operator’s responsibility. If you haven’t done that course yet, start there.

Sources: the LaserCube Ultra MK2 & Pro manual, and our video tutorials. If a video and the manual differ, follow the manual.

Lesson 1 of 8

Pick a control mode

The control mode decides who is in charge of the laser: software on a computer or phone, the cube itself, or a lighting desk. One mode is active at a time.

Beginners guide, part 5: control modes, LaserOS (0:00 to 4:39)Watch on YouTube

The video arms a cube with the safety jumper. In the US the cube runs with an E‑Stop instead (Laser safety, lesson 6).

The eight control modes

The cube plays on its own, from its SD card. No computer needed.

  • Playlist: plays playlists you made in LaserOS (lessons 2 and 3).
  • Visualizer: 197 built‑in visuals that react to sound, since firmware 2.2 (lesson 4).
  • Laser Show: ready‑made laser shows with music, on one cube or several (lesson 5).

A lighting desk is in charge

  • DMX: a DMX desk or controller, over a DMX cable (lessons 6 and 7).
  • Art‑Net: the same control over the network, from desks and software that speak Art‑Net.

Software streams to the cube over the network

  • LaserOS: LaserOS is in complete control: the mode you used in Laser safety, lesson 7. It’s also the mode for supported third‑party apps such as Liberation, LaserShowGen and MadMapper.
  • IDN: the ILDA Digital Network protocol, streaming up to 35,000 points per second.
  • Ether Dream: the Ether Dream network protocol, for third‑party laser software such as TouchDesigner (manual: Ether Dream Control Mode). Unlike LaserOS mode, the cube’s own Image Setup, Colour Balance and Safety Zone still apply.

ILDA input: other show software can send its signal through its own interface box (a DAC) into the ILDA input, the standard laser show connector. The cube switches to it by itself, overriding the current mode. The manual suggests 30,000 points per second in that software, and raising In Mute under Settings → ILDA Input Cfg if a faint beam stays on.

IDN and Ether Dream: what they are, then switching the cube to IDN and to LAN client (0:17 to 1:15)

Filmed on firmware 2.0. On firmware 2.1 and later, changing the connection mode doesn’t restart the cube. For a cable straight to one computer, the manual recommends LAN server (Connect, lesson 3).

Change the mode

  • On the cube’s screen, choose Control Mode in the main menu, then the mode. Turn the knob to move, push it to select.
  • When you choose DMX or Art‑Net, the cube restarts in that mode, and its DMX or ArtNet menu appears in the main menu.
  • The status bar at the bottom of the screen shows the current mode, the connection and the cube’s IP address, plus an I‑LOCK warning while the laser isn’t armed: it’s armed only with the interlock closed and the key on, and with an E‑Stop, the E‑Stop started (Laser safety, lesson 6).
  • Its background colour tells you more: green while the cube receives laser data over the network, cyan while the ILDA input is in use, and purple on a Cube Link slave that has found its master (lesson 5).
The cube’s screen, from the manual. The main menu has Control Mode, Settings, Preview and Status Info. The Control Mode list shows Playlist ticked, then Laser Show, IDN and Ether-Dream. The status bar at the bottom shows the battery level, WiFi status and channel, the laser data rate (35K), the I-LOCK warning, the current control mode, the network connection mode and the cube’s IP address.
The main menu, the Control Mode list and the status bar, from the manual. Select the picture to open it full size in a new tab.

Which settings the cube uses

  • In LaserOS mode, LaserOS handles the image setup, colour balance and safety zones, so those entries are greyed out on the cube.
  • When you choose one of the cube’s other modes, such as Visualizer, the cube’s own settings become available under Settings → Projection: Image Setup (power, zoom, rotation, size, flip, position and, since firmware 2.2, keystone), Colour Balance and Safety Zone. Set the safety zone there, as in Laser safety, lesson 8.
It can start by itself

In Playlist mode, the last playlist starts as soon as the interlock is enabled, because Power‑On Play is on by default. Effect settings you change on the cube are kept after a power cycle. So once the key is on and the interlock is ready (with an E‑Stop, after the E‑Stop start), the show may start straight away.

Before you start: update the firmware

  • This course follows the manual, which is written for firmware 2.2. Where older firmware differs, for example fewer visualizers, a simpler web app or a restart when you change the connection mode, the lessons say so.
  • The manual’s preferred way to update is the SD card: when the card has newer firmware, the cube asks whether to update. The latest card contents on GitHub (lesson 2) include the newest firmware.

Updating the firmware from the SD card (2:21 to 3:34)Watch on YouTube, from 2:21

The cube asks to update to the version on the card: v2.0 in the video, a newer number with today’s card contents.

Check yourself

Question 1At a party you want the cube to play your logo and a few animations, with nothing streaming to it: no computer or phone. Which mode?
Question 2You’re running the Visualizer. Where do you set the safety zone?
Question 3The cube is in Playlist mode with the factory settings. You switch on, turn the key on and the interlock is ready. What happens?

Lesson 2 of 8

Build a playlist in LaserOS

Playlist mode plays the content you choose, straight from the SD card. You build the playlist in LaserOS on a computer, then copy it to the card.

Importing a playlist to the SD cardWatch on YouTube

Filmed on older firmware and LaserOS 0.17.7: the menus look a little different now. The steps below follow the manual.

The SD card

  • The microSD card in the cube holds the content for the stand‑alone modes, DMX, Art‑Net and MIDI: the built‑in laser shows, demo playlists and MIDI mappings come on it.
  • Missing files? The latest card contents, including the newest firmware, are on GitHub. Unzip them and copy the “Lasercube” folder to the root of the card. Deleting the old folder also deletes your own playlists and MIDI mappings, so rename it first and copy your own files from it into the new one.
  • Need a new card? The one the manual names as tested is the Lexar A2 Silver Plus 64GB. Cheaper cards may fail to stream the laser shows. If you format it, use exFAT, and name the card “WL”.
  • Always switch the cube off before you take the card out or put it in. Never remove or insert it while the cube is on.

Make the playlist

  • Use LaserOS 0.18.1 or later on a Windows or Mac computer. The phone and tablet apps only stream to the cube: they can’t put content on its SD card.
  • Open the Playlists app, click the small + and save the new playlist. Keep the name short: the cube’s screen can only show a limited number of characters.
  • Add content: drag cues (each item in LaserOS, such as an animation, is a cue) into the playlist pane on the right, or right‑click any cue, pick your playlist under “Add To Playlist” and click Add.

Add your own logo

  • Open the Import app, pick the playlist, then click “Import files”. SVG and ILD files give the best results. A PNG or JPG is first turned into lines, in a window where you adjust sensitivity, line length and more, with a live preview.
  • A very detailed image can flicker: the scanners can only draw so many points per second. Turn on “Show FPS” in LaserOS (Settings → General). At 45 frames per second or more, it won’t appear to flicker.
  • If it flickers, lower its render quality: right‑click the item in the playlist, turn on “Assign render quality” and move the slider down.

How long each item plays

Right‑click an item and turn on “Assign Duration”. Choose time (1 to 999 seconds) or cycles (how many times an animation plays, 1 to 999). One cycle suits scrolling text from the Text app: it scrolls once, then the next item plays. The “Beats” duration and “Assign Effect” aren’t supported on the cube.

Copy it to the SD card

  • Switch the cube off and take out its microSD card. Put the card in a USB 3.x card reader and connect it to the computer. It shows up as a drive called WL, with a folder called “Lasercube”.
  • In the Playlists app, select the playlist and click the SD card export button. If the computer asks for access to the card, allow it. If the playlist is already on the card, you can replace it.
  • “SD card not found”? Check that the card is properly in the reader, that it’s named WL (rename it if not) and that it has the Lasercube folder (if not, get the card contents from GitHub, above).
  • On the card, each playlist is a “.ldpl” file plus a folder with the same name. The cube only lists the playlist if both are there. The .ldpl file is plain text, and its order is the play order (with shuffle off).
  • Eject the card safely before you take it out of the reader. With the cube still off, put the card back in, then switch the cube on.

Playlist mode: exporting your own playlist to the SD card (5:13 to 6:22)

Switch the cube off before you take the card out, and put the card back only while the cube is off.

Check yourself

Put the steps for a new playlist in order.

  1. Make and save a playlist in LaserOS on a computer
  2. Add cues and import your logo
  3. Switch the cube off, take out the card and export the playlist to it in a USB 3.x reader
  4. Eject the card safely
  5. Put the card back in the switched‑off cube, then switch it on
Question 1You want to export a playlist to the cube’s SD card from LaserOS on your phone. Will that work?
Question 2Your imported logo flickers on the cube. What helps?
Question 3LaserOS says “SD card not found”, but the card is in the reader. What do you check?

Lesson 3 of 8

Play it on the cube

Now play your playlist: from the cube’s own screen, or from a web browser on your phone or laptop.

The Playlist Player

Playlist mode: the Playlist Player and Playlist Options on the cube (0:23 to 2:13)

Power‑On Play starts the last playlist once the interlock is enabled after switching on (Playlist options, below).

  • With the card in the cube, choose Control Mode → Playlist, open the Playlist Player and pick your playlist. The cube remembers it after a power cycle.
  • Auto‑Play moves on to the next cue every “cue delay” seconds. Press pause to stay on the current cue.
  • Picking a cue yourself, with previous or next, the web app or an APC button, stops the auto‑play until you press play again.
  • Shuffle plays the cues in random order. Settings → Playback Speed changes how fast each cue’s animation runs.
  • In Playlist mode the cube’s own Image Setup and Safety Zone apply, not the ones in LaserOS: set them on the cube before you play (Settings → Projection, lesson 1).
The Playlist Player screen, from the manual: a playlist drop-down showing Beams 1, then buttons for previous cue, auto-play play and pause, next cue and projection on or off, and a Cue Delay slider set to 66 seconds. Notes say previous and next cue turn auto-play off.
The Playlist Player on the cube, from the manual. Select the picture to open it full size in a new tab.

Playlist options

The Playlist Options menu sits below the Playlist Player in the main menu.

  • Fade: how fast one item fades out and the next fades in. The default is 250 ms; 0 ms means no fade.
  • Power‑On Play: on by default. The last playlist starts projecting as soon as the interlock is enabled after switching on. Set it to Disabled if you want the cube to wait until you press the projection button in the player or the web app.
  • Web html: the factory web app, or your own version of it from the SD card.

Control it from a browser

The playlist web app: pick a playlist, then a cue (6:41 to 7:30)Watch on YouTube, from 6:41

Filmed on older firmware. Since firmware 2.2, the three buttons at the bottom left open Picture settings, Player settings and Effects (below).

  • Connect your phone or laptop to the cube, the same way as for LaserOS. With WiFi server, join the cube’s WiFi: “LaserCube”, password “Laser2020”, unless you changed them.
  • Open a web browser (Safari, Chrome or Firefox) and type the cube’s IP address: 192.168.4.1 by default on WiFi server. It’s also shown at the bottom right of the status bar.
  • Pick a playlist at the top right, and tap a cue to play it.
  • Picture settings: the cube’s projection settings in five tabs. Image has power (0 to 100%), zoom (10 to 100%), rotation (up to 90° either way), the picture’s size and position, the keystone, flips and a grid; then Colour, Safety (the safety zone), Test (test patterns) and Preview, the laser output live on your phone. Press Save to keep the changes.
  • Player settings: shuffle, cue delay, fade time and play speed (100 is normal speed), the audio input with a live spectrum, and the page’s theme. The status bar above the buttons shows the WiFi signal, the cube’s temperature and the battery.
  • Effects: one image effect and one colour effect at a time (lesson 4).
  • These are the buttons of firmware 2.2. Older firmware has a simpler web app with quick image settings (rotation, zoom and power), quick player settings and a quick effect menu.
The playlist web app of firmware 2.2 on a phone, from the manual: the cube tabs and Rescan at the top, the cue playing and the playlist, a grid of cue previews, the status bar, and along the bottom the Picture settings, Player settings and Effects buttons, projection on or off, and previous, auto-play and next.
The playlist web app of firmware 2.2, from the manual. The projection button is red while the laser is on. Select the picture to open it full size in a new tab.

Check yourself

Question 1You don’t want the playlist to start as soon as the interlock is ready after you switch on. What do you change?
Question 2Auto‑Play is running and you tap a cue in the web app. What happens next?
Question 3Your phone is on the cube’s WiFi, which uses the factory settings. Which address opens the web app?

Lesson 4 of 8

Visualizer: shows that follow the music

In Visualizer mode the cube draws its own visuals that react to sound. There’s no playlist to build and no computer to connect.

Pick a visual

Visualizer mode on the cube: player, options and preview (0:22 to 2:39)

  • Firmware 2.2 has 197 sound‑reactive visualizers; a cube on older firmware has fewer (firmware 2.0 has 91) until it is updated. They include spectrum and waveform meters, particles and trails, geometric patterns, beams and mirrors, dancing characters and 21 Halloween figures. The manual lists all 197, with a picture of each.
  • Choose Control Mode → Visualizer. Pick a playlist (“All” has every visual), then a visual, or let auto‑play move through the list. Picking a visual yourself, or pressing previous or next, cancels the auto‑play.
  • The Viz Options menu sets the transition time between visuals. Auto‑play at power‑on, the cue delay, shuffle and the web app’s source can be set there too.
The Audio Visualizer screen, from the manual: a playlist drop-down set to Classics, a visual drop-down set to Atomic, and buttons for previous, auto-play play and pause, next and projection on or off. Notes say that choosing a visual, previous or next cancels auto-play.
The Visualizer player on the cube, from the manual. Select the picture to open it full size in a new tab.

Give it sound

  • Settings → Audio → Audio Input: the built‑in microphone, or the line input. For the line input, plug the audio from a computer or another audio device into the pink 3.5 mm jack marked A‑IN.
  • Gain (Max Line Gain or Max Mic Gain, 0 to 50 dB in 5 dB steps): too low and some visuals hardly move; too high and they’re overdriven.
  • Settings → Tempo: some visuals and effects follow the tempo. Press “Tap BPM” in time with the music so the cube works out its beats per minute, then press “Sync Beat” on the first beat of a bar.

Effects

  • In Playlist and Visualizer modes, the Effects menu adds effects that warp or re‑colour the image: zooms, 3D spins, ripples, colour cycles, strobes and more, 78 in all. Most react to the sound or the tempo.
  • Effects only work once they’re enabled. The manual recommends keeping them disabled when you don’t need them, so the projection doesn’t change by accident.
  • The Master Effect slider sets how strongly all effects apply: 100% by default; at 0% no effect is applied.
  • Effect settings you change on the cube are kept after a power cycle.
  • In the web app’s Effects menu, you pick one image effect and one colour effect at a time; “No Effect” turns one off.

The Visualizer web app

Visualizer mode uses the same web app as Playlist mode, with the visuals in its grid. In it you pick playlists and make your own: press and hold a visual to add it to a playlist, and press one and slide it sideways to change the order. “All” and the built‑in playlists, such as “Classics”, can’t be deleted. Its settings add a BPM tab with Tap BPM and Sync Beat (firmware 2.2). If the previews show as blank squares, update the SD card from GitHub (lesson 2).

Opening the Visualizer web app on a phone (2:49 to 3:55)

Filmed on firmware 2.0. On firmware 2.1 and later, changing the connection mode doesn’t restart the cube and the web app looks different: the text above and lesson 3’s “Control it from a browser” follow firmware 2.2.

Check yourself

Question 1The music through the line input is loud, but the visuals barely move. What do you adjust?
Question 2Which sound can the Visualizer react to?
Question 3You don’t need any effects tonight. What does the manual recommend?

Lesson 5 of 8

Laser shows on one cube or several

Laser Show mode plays ready‑made shows with music, from the SD card. With Cube Link, several cubes play them in sync, with no computer and no WiFi network.

Play a built‑in show

Laser Show mode: picking a show, a speaker on A‑OUT, preview and settings (0:00 to 4:19)

The shows come on the cube’s SD card. If yours are missing, the latest card contents are on GitHub (lesson 2).

  • Choose Control Mode → Laser Show, pick a category, then press play. There are 38 shows in 7 categories: EDM, Christmas, Thanksgiving, New Year, Birthday, Wedding and Halloween. When a show ends, the next one in the category starts.
  • Empty list? The SD card is missing, or it doesn’t have the factory contents (lesson 2).
  • The music comes out of the green 3.5 mm jack marked A‑OUT: connect powered speakers. Settings → Audio → Audio Output Volume sets the level.
  • Some speakers with built‑in light effects delay the sound, by as much as 300 ms. Then use Audio Output Delay to bring the music and the laser back in sync. A new delay applies when you stop and start the show again.

Several cubes with Cube Link

Setting up Cube Link: range, master, slaves and a first test (1:57 to 4:07)Watch on YouTube, from 1:57

Cube Link groups, then a speaker on A‑OUT (4:32 to 6:10)Watch on YouTube, from 4:32

Filmed on older firmware. The PIN box opens with a short press, and on firmware 2.1 changing the connection mode doesn’t restart the cube.

  • Cube Link makes its own wireless link between the cubes, over about 20 to 40 m with a clear line of sight. Connect the WiFi antenna on every cube first.
  • Each cube plays from its own SD card, with its own settings. The master only tells the others what to play and when.
  • It works on the Pro too, also together with an Ultra MK2. (The videos above show only Ultra MK2 cubes.)
  • It’s under Settings → Network → Cube Link, and it’s only available when the connection mode isn’t WiFi. If it is, choose a LAN mode under Settings → Connection first (on firmware older than 2.1, the cube restarts).
  • On every cube, choose Laser Show mode, enable Cube Link and set the same Link Channel and the same PIN. For the PIN, highlight the PIN box and short‑press to open it; turn the knob to change the highlighted digit, short‑press to move to another digit, and long‑press to close it.
  • Make one cube the Master and all the others Slaves.
  • Set each cube’s Group. A show made for two projectors, such as Alive (2CH), has two parts: Group 1 cubes play one, Group 2 cubes the other. With four cubes, put two in each group.
  • A slave that has found its master shows a purple status bar. Status Info shows how many slaves are connected (“Remote Slaves”).
  • Pick the same show category on every cube. Once every slave’s status bar is purple, press play on the master: that starts them all.
Every cube is its own laser

Pressing play on the master starts lasers that may be 20 to 40 m away. Each cube has its own key and interlock. On every cube: its beam block set (Laser safety, lesson 8), and where people could get into its beams, every beam and where it lands in view of someone who can get that laser stopped at once (Laser safety, lesson 4).

The Cube Link menu on a master cube, from the manual: Enable is on and Cube Link is set to Master. The status bar is black.
Master: Cube Link enabled and set to Master.
The Cube Link menu on a slave cube, from the manual: Enable is on and Cube Link is set to Slave. The status bar is purple and reads Laser Show.
Slave: the purple status bar means it has found its master.

Other tips for several cubes

  • In the cube’s own modes, such as Laser Show, you can fine‑tune each cube’s colours in Settings → Projection → Colour Balance, to match several projectors. The defaults suit most situations. In LaserOS mode, LaserOS handles colour balance.
  • To stream to several cubes from LaserOS, or where WiFi is busy, the manual recommends network cables in LAN client mode (Connect, lesson 3).

Check yourself

Put the Cube Link set‑up in order.

  1. Connect the WiFi antenna on every cube
  2. Set a LAN connection, then enable Cube Link on every cube
  3. Set one Master and the rest Slaves, all on the same channel and PIN
  4. Check that every slave’s status bar turns purple
  5. Press play on the master
Question 1The music from your speakers lags behind the laser show. What do you use?
Question 2Four cubes will play a show made for two projectors. How do you set them up?
Question 3One slave’s status bar stays black. What do you check?

Lesson 6 of 8

Connect a DMX or Art‑Net desk

With DMX or Art‑Net, a lighting desk runs the cube alongside your other lights. The cube plays cues from a playlist on its SD card; the desk picks the cue and can change its size, position, colour and more.

What DMX is: addresses, values and start addresses (0:18 to 2:14)Watch on YouTube, from 0:18

DMX or Art‑Net?

  • DMX: a DMX cable from the desk or controller into the cube’s DMX In.
  • Art‑Net: the same control over the network (Ethernet), from desks and software that speak Art‑Net. Connect a network cable and choose the connection under Settings → Connection, for example LAN client (Connect, lesson 3).

Who runs the laser: whoever runs the desk is running a Class 4 laser. The manual says only people trained in laser safety may operate it, and the rules from Laser safety still apply: two ways to stop it, tested before the show, and where people could get into the beams, every beam in view of someone who can stop the laser.

Beginners guide, part 6: control modes, Art‑NetWatch on YouTube

Filmed on firmware 2.0. On firmware 2.1 and later, changing the connection mode doesn’t restart the cube. Two corrections: the cube’s projection settings are greyed out in LaserOS mode, because LaserOS handles them (lesson 1); and Auto IP doesn’t need a DHCP server: without one, the cube gives itself a 169.254 address (Connect, lesson 3).

DMX cables

  • Ultra MK2: full‑size XLR DMX In and Out. Standard DMX cables plug straight in.
  • Pro: DMX In and Out are two 3.5 mm TRS jacks (headphone‑size sockets), In on the left and Out on the right. Each needs an adapter cable, not included: for DMX In a 3.5 mm TRS plug to 3‑pin XLR male (the end with pins), for DMX Out a 3.5 mm TRS plug to 3‑pin XLR female (the end with holes).
  • Both Pro cables are wired tip to XLR pin 3, ring to pin 2, sleeve to pin 1. Ordinary 3.5 mm‑to‑XLR audio cables are wired the other way round, so they won’t work. The manual names Eurolite’s “DMX‑Adapter IN Jack 3,5/XLR” and “DMX‑Adapter OUT Jack 3,5/XLR”.
  • Only real DMX gear on the line: lights and true DMX fog machines can share the line with the cube. But most fog machines aren’t true DMX: their XLR socket is a remote socket, and many put mains power on it, which damages the cube. Never connect a fog machine unless you’re sure it’s true DMX, even if a DMX cable fits.

Set it up on the cube

  • Choose Control Mode → DMX‑512 (or ArtNet). The cube restarts, and the DMX (or ArtNet) menu is now in the main menu.
  • Start Address: where the cube’s 16 channels begin, from 1 to 512 (default 1). Set the same address for the cube on your desk.
  • Universe (Art‑Net only): the Art‑Net universe, a numbered set of 512 channels on the network, that the cube listens to.
  • Fixture Profile: decides which channel controls which feature. There’s one, with 16 channels (lesson 7; the channel map is also a PDF on the factory SD card). It’s compatible with the FB3/FB4 16‑channel profile, so desks that support FB3/FB4 should work with it.
  • CUE Selection: the playlist on the SD card that the desk picks cues from. Cue 1 is the playlist’s first item. Export your own from LaserOS (lesson 2) or use one that came on the card.
  • Defaults puts every item in the menu back to its factory setting.

Beginners guide, part 7: control modes, DMX (0:30 to 1:33)Watch on YouTube, from 0:30

The start address in the video isn’t the default of 1.

The main menu in DMX-512 mode, from the manual: Control Mode, Settings, Preview and a new DMX item. The status bar shows a red cross next to DMX.
After the restart: a DMX item in the main menu. The red cross means no DMX is arriving yet.
The DMX menu, from the manual: Start Address 001 and Fixture Profile default (16 CH). The status bar shows a green tick next to DMX.
Start address 1, the 16‑channel profile, and a green tick: DMX is arriving.

Is it receiving?

  • At the bottom right of the status bar, a green tick next to DMX means the cube is receiving; a red cross means it isn’t.
  • DMX red cross with the desk running: check the cabling, and that the DMX line is correctly terminated.
  • Art‑Net red cross: check the network first (is an IP address shown in the status bar?), then that the cube is on the right universe.
  • MIDI controllers don’t work in DMX or Art‑Net mode (lesson 8).

Check yourself

Question 1You connect a Pro to a DMX desk with a 3.5 mm‑to‑XLR audio cable. Will it work?
Question 2On your desk, the cube’s 16 channels are 101 to 116. What do you set on the cube?
Question 3Your desk tells the cube to play cue 1. Which item plays?

Lesson 7 of 8

The 16 DMX channels

The cube uses 16 channels, starting at its start address. The same channels work over DMX and Art‑Net. Each channel carries a value from 0 to 255, and the tables show what each range does. Channel 1 decides how many of them the cube listens to.

Channel 1: access mode

ValueModeChannels used
0⁠–⁠31Blackoutnone
33⁠–⁠95Basic1⁠–⁠4
97⁠–⁠159Standard1⁠–⁠8
161⁠–⁠223Extended1⁠–⁠12
225⁠–⁠255Fullall 16

Channels above the mode’s range keep their default values. The values 32, 96, 160 and 224 don’t change the mode.

Picking a cue: channels 2 and 3

  • Channel 3, cue: picks one of 48 cues. 0⁠–⁠31 is blackout, 33⁠–⁠35 is cue 1, 37⁠–⁠39 is cue 2, and so on up to 221⁠–⁠223 for cue 48.
  • Channel 2, page: moves on in steps of 48 cues. 0⁠–⁠15 is page 1 (cues 1⁠–⁠48), 17⁠–⁠31 is page 2 (cues 49⁠–⁠96), and so on up to page 9 (129⁠–⁠255). That’s up to 432 cues in a playlist.
  • Example: cue 50 of your playlist is page 2 (channel 2 at 17⁠–⁠31), cue 2 on that page (channel 3 at 37⁠–⁠39).

A first test

Send channel 1 at 33⁠–⁠95 (Basic), channel 2 at 0⁠–⁠15 (page 1), channel 3 at 33⁠–⁠35 (cue 1) and channel 4 at 0⁠–⁠15 (normal speed). The cube plays the first item of the CUE Selection playlist, at full brightness and full size (in Basic, channels 5 and 6 stay at 100%). With every channel at 0, it shows nothing: channel 1 at 0 is blackout.

A first test from a DMX app: 4‑channel (Basic), then 8‑channel (Standard) mode (7:59 to 9:30)Watch on YouTube, from 7:59

The app shows the values as percentages. In 8‑channel (Standard) mode he raises the fader and the scale, or nothing would show (channels 5 and 6, below).

The other channels

  • 4, Speed: 0⁠–⁠15 normal speed; 17⁠–⁠31 pause; 33 to 255 runs from 25% to 200% (128 is 100%).
  • 5, Fader (Standard and up): black to full brightness.
  • 6, Scale (Standard and up): zero to full size.
  • 7 and 8, X size and Y size (Standard and up): 128 is zero size, 255 full size, and 0 full size mirrored (X) or flipped upside down (Y).
  • 9, Rotation (Extended and up): 0 to 360°.
  • 10 and 11, X and Y position (Extended and up): 128 is the centre.
  • 13, Scan rate (Full only): 0⁠–⁠31 the default, 35K points per second; 33⁠–⁠223 from 6K to 29K; 225⁠–⁠255 30K.
  • 15, Recolour (Full only): 0⁠–⁠31 the cue’s own colours; 33⁠–⁠223 one colour, from red through the rainbow back to red; 225⁠–⁠255 white.
  • 12, 14 and 16: reserved, not used yet.

Below the mode a channel needs, the cube uses that channel’s default: fader and scale at 100%, no rotation, the image centred, the default scan rate and no recolouring.

Safety: channels 6 to 11 let the desk resize, flip, rotate and move the image. Whatever the desk sends, the beam block is your hard stop: set and check it before the show, as in Laser safety, lesson 8.

Check yourself

Question 1The desk sends 0 on channel 1. What does the cube do?
Question 2Channel 1 is at 50 (Basic). You raise the fader on channel 5. What happens?
Question 3You want cue 50 of the playlist. Which values do you send?

Lesson 8 of 8

MIDI controllers

Plug an APC40 MK2 or APC mini MK2 into the cube’s USB port, and you get real buttons, knobs and faders for cues, effects and settings. No computer in between.

Connecting a MIDI controllerWatch on YouTube

Filmed on firmware 1.14: some buttons and knobs may work differently now. The steps and tables below follow the manual.

Connect it

  • Plug the APC40 MK2 or APC mini MK2 into the USB port, then turn on Settings → USB MIDI. A green tick next to MIDI in the status bar means it’s connected.
  • MIDI works in Playlist, Visualizer and Laser Show modes. It doesn’t work in LaserOS, Art‑Net, DMX, IDN or Ether Dream mode: those are controlled another way. In LaserOS mode, plug the controller into the computer running LaserOS instead, and set it up in LaserOS under Settings → Midi.
  • To save your mappings, an SD card must be in the cube. They’re stored in its /Lasercube/settings folder, one file for each controller and control mode, as plain text you can also edit.

The ready‑made mapping

  • The SD card that comes with the cube has ready‑made mappings for the APC40 MK2 and the APC mini MK2. In the APC40 MK2 one, the blue items work in Playlist mode, the red ones are effects (Playlist and Visualizer modes), and the yellow ones are image settings for the whole cube, such as power, rotation, zoom and position. The tempo buttons are mapped too. The Master fader is the master effect intensity: no effect shows until it’s above 0%.
  • In Playlist mode, the playlist’s items are put on the APC’s grid buttons by themselves. To choose the button and colour for each item, edit the playlist’s .ldpl file (the manual explains the apc_note and apc_color fields).
The default APC40 MK2 mapping, from the manual. In blue: the grid of buttons selects cues from the current playlist, the scene buttons select the playlist, Play stops and starts the playlist, and one dial sets the cue speed. In red: the top dials set the speed or colour of the colour cycle, zoom, hue, colorize, flash and strobe effects, and the faders below set each effect’s intensity, plus a master effect intensity. Metronome is Sync Beat, Tap Tempo and the tempo dial set the tempo. In yellow: dials for power, rotation, zoom, X position and Y position.
The default APC40 MK2 mapping on the factory SD card, from the manual. Blue: Playlist mode; red: effects; yellow: image settings. Select the picture to open it full size in a new tab.

Map your own controls

  • A slider to a knob or fader: on the cube’s screen, push the knob on the slider to edit it, then long‑press for the menu and choose “Link MIDI Knob”. Then move the control on the APC.
  • If that control is already mapped to something else, its MIDI info shows orange. Accept it, and it moves to this slider.
  • A mapped slider shows yellow on the screen instead of blue. Almost every slider can be mapped. Since firmware 2.2, none of the Colour Balance and Safety Zone controls (sliders or switches) can, and links made to them on older firmware stop working.
  • APC40 faders are absolute: moving one always overrides the slider’s value. The dials turn without end stops, and the LED ring around each mapped dial shows the slider’s value.
  • Buttons, switches and drop‑down lists (such as the playlist or the laser show list): highlight it (in a list, pick the item first), long‑press, choose “Link MIDI Note”, press a button on the APC and pick its light colour, one of 15. After updating from firmware older than 2.2, link the Test Patterns Enable switch again, to the same APC button.
  • To remove a mapping, open the same menu and choose Unlink.

Safety: with the factory mapping, the yellow dials change the power, rotation, zoom and position of the image while it plays. Whatever the controller sends, the beam block is your hard stop (Laser safety, lesson 8).

Check yourself

Question 1The cube is in DMX mode. You plug in an APC40 MK2, but nothing reacts. Why?
Question 2Your own mappings are gone every time you restart the cube. What’s missing?
Question 3A slider on the cube’s screen shows yellow. What does that mean?

Final quiz

Final quiz

10 questions picked at random, one from each of the course’s 10 topics. Get 8 right to pass. You can try as many times as you like.

Certificate

Your certificate

Pass the final quiz to get your certificate. Go to the final quiz
